Product Overview
The ZTE ZXD1500(V4.0) is compact high-density digital switching rectifier independently developed by ZTE, specially matched with ZXDU58, ZXDU300 series small-capacity embedded telecom power cabinets, also supports standalone DC power application. Rated 1500W/30A@default53.5VDC, it converts 80~300VAC wide single-phase alternating current into adjustable 42~58VDC standard telecom voltage for lead-acid/lithium battery float & equalized charging. Adopts advanced high-frequency switching + full active PFC technology, conversion efficiency reaches above94%, full-load PF≥0.99 and low grid harmonic pollution, compact size with ultra-high power density. Standard drawer hot-swap plug design enables online replacement without cabinet shutdown; built-in monitoring communication interface to connect cabinet CSU control unit for remote parameter adjustment, widely used for mini FTTx OLT, DSLAM and indoor compact 4G small cell power matching & old cabinet spare replacement projects.
Key Features
Ultra-wide AC input:80~300VAC(50/60Hz, nominal100~240VAC), well adapt unstable rural grid and diesel generator power supply
Adjustable DC output:42~58VDC(default53.5V), rated30A/1500W, precise voltage regulation ≤±0.6% for different battery charging modes
Active full-range PFC design, full-load PF≥0.99, THD≤5%, ≥94% working efficiency to lower daily power consumption
Compact slim structure, front pull-out full hot-swap construction, rapid maintenance without cutting off system power
Intelligent thermostatic forced air cooling fan, auto speed adjustment based inner temperature to reduce operating noise and extend lifespan
Comprehensive multi-protection:AC OVP/UVP, DC OVP/OCP/SCP/OTP plus input surge protection
Digital communication linkage with ZTE original monitoring unit, multi-module automatic parallel current sharing without extra accessories
Wide working range:-33℃~+55℃ full-power output, storage:-40℃~+70℃, max3000m full-load altitude, CE & ISO certified
Technical Specifications
| Item | Details |
| Model | ZXD1500(V4.0) |
| Brand | ZTE / XDSD |
| AC Input | 80~300VAC,50/60Hz,Nom100~240VAC,Max8A |
| DC Output | Adjustable42~58VDC(Nom53.5V),Nom30A/1500W |
| Rated Efficiency | ≥94% |
| Full Load PF | ≥0.99 |
| Dimension | 300×40×130mm |
| Net Weight | 2.0kg |
| Cooling | Intelligent Thermostatic Forced Air Cooling |
| Working Temp | -33℃ ~ +55℃(Full Power) |
| Storage Temp | -40℃ ~ +70℃ |
| Max Full-power Altitude | ≤3000m |
| Certifications | CE,ISO |
| MOQ | 1 PCS |
| Unit Price | $149/PCS(1~9pcs) |
| Monthly Supply | 1500PCS |
| Packing | PE Bag+Foam+Export Standard Carton |
| Warranty | 12 Months |
Applications
ZXDU58/ZXDU300 Series Small Cabinet Matching Embedded DC Power Module
Indoor Mini FTTx OLT & DSLAM Cabinet Auxiliary Power Supply
Compact Indoor 4G/5G Micro Small Cell Backup Rectifier Replacement
Small Industrial Equipment 48V DC Power Source Configuration
Rural Mini Off-Grid Solar Battery Charging Power Unit
Old Small-capacity ZTE Power Cabinet Capacity Expansion Project
