Product Overview
The ZTE ZXD2400 V4.3 is original high-reliability digital switching rectifier developed by ZTE, specially designed to match ZTE ZXDU68, ZXDU58 series embedded & outdoor integrated telecom power cabinets. Rated 2900W nominal output, peak up to 3000W@53.5VDC/50A, it converts 80~300VAC wide-range single-phase alternating current into adjustable 42~58VDC standard telecom voltage. Adopts soft-switch + full active PFC design, full-load PF≥0.99, rated efficiency≥90%, excellent anti-fluctuation performance for unstable rural and diesel generator grids. Standard drawer hot-swap plug structure allows online maintenance without system shutdown; built-in RS485/CAN communication interfaces connect with ZTE CSU monitoring unit for remote voltage setup, real-time data collection and fault alarm, widely used in pole-mounted FTTx OLT, indoor/outdoor 4G/5G micro base station and old ZXDU cabinet renovation projects。
Key Features
Ultra-wide AC input:80~300VAC(45~65Hz, nominal100/220V dual grid compatible), automatically derate below 110VAC to protect module safety
Adjustable DC output:42~58VDC continuous regulation(default53.5VDC), max50A constant current, voltage precision≤±0.6%
Full active PFC design, full-load PF≥0.99, low THD＜5%, effectively reduce grid harmonic loss and long-term electricity expense
Front pull-out full hot-swap design, plug & play without cabinet power cut, shorten field repair downtime
Intelligent temperature-variable cooling fan, auto adjust rotating speed based internal temperature to lower idle noise and extend service life
Complete multi-protection:AC OVP/UVP, DC OVP/OCP/SCP/OTP plus input lightning surge protection and anti-reverse connection circuit
RS485+CAN dual communication, realize multi-module automatic current sharing and remote parameter configuration via cabinet monitor
Wide ambient adaptability:-5℃~+65℃ full-power working, stable storage -40℃~+70℃, full-power below 2000m altitude
Technical Specifications
| Item | Details |
| Model | ZXD2400 V4.3 |
| Brand | ZTE / XDSD |
| AC Input | 80~300VAC,45~65Hz,Nom100/220VAC,Max18A |
| DC Output | Adjustable42~58VDC(Nom53.5V),Nom2900W/Max3000W,50A |
| Rated Efficiency | ≥90% |
| Full Load PF | ≥0.99 |
| Dimension | 134×87×318mm |
| Net Weight | 3.8kg |
| Cooling | Intelligent Variable Speed Forced Air Cooling |
| Communication | RS485+CAN Bus |
| Working Temp | -5℃ ~ +65℃(Full Power:-5~+45℃) |
| Storage Temp | -40℃ ~ +70℃ |
| Max Full-power Altitude | ≤2000m |
| Certifications | CE |
| MOQ | 1 PCS |
| Unit Price | $98/PCS(1~9pcs) |
| Monthly Supply | 1000PCS |
| Packing | PE Foam + Export Standard Carton |
| Warranty | 12 Months |
Applications
ZXDU Series Indoor & Outdoor Cabinet Matching Embedded DC Power Module
Pole-mounted FTTx OLT & DSLAM Outdoor Cabinet Backup Power Supply
Indoor/Outdoor 4G/5G Micro Small Cell Rectifier Replacement
Old ZTE ZXDU Power Cabinet Capacity Expansion Upgrade Project
Mini Edge Server Room Auxiliary Uninterrupted DC Power
Rural Off-Grid Solar Hybrid Telecom Station Matching Power Unit
