Product Overview
The Vertiv (formerly Emerson) R48‑3500e3 is a high‑power, ultra‑high efficiency eSure series rectifier module designed for mission‑critical telecom and data center power systems. It converts wide‑range AC input into stable adjustable –48V DC output, delivering rated power 3500W and max output current 73A. It is widely used in 4G/5G base stations, OLT equipment, edge data centers, microwave transmission and compact embedded power systems.
Adopting advanced DSP digital control and high‑frequency LLC resonant topology, this module achieves peak efficiency up to 96.3%, with features including hot‑swap capability, active current sharing, comprehensive protection and strong environmental adaptability. It is a core component for reliable, energy‑saving and maintenance‑free DC power supply.
Key Features
Ultra‑high peak efficiency up to 96.3%, low power consumption and heat generation
Wide AC input range 85–305VAC, 45–65Hz, compatible with global unstable power grids
Stable adjustable DC output –42V ~ –58VDC, max current 73A, rated power 3500W
Power factor >0.99, THD ≤5%, green and grid‑friendly design
Hot‑swappable design, online replacement without system shutdown
Automatic digital current sharing, current imbalance ≤±3%, supports parallel expansion
Tri‑color LED indicators (green/yellow/red) for real‑time status monitoring
CAN bus communication, reports voltage, current, temperature and fault alarms
Wide operating temperature –40°C ~ +75°C, strong high‑temperature resistance
Full protection: OVP, OCP, SCP, OTP, input undervoltage
Ultra‑compact size, light weight, easy for rack integration
Certified with CE, UL, ETSI, RoHS and global telecom standards
Technical Specifications
| Item | Details |
| Brand | Vertiv / Emerson |
| Model | R48‑3500e3 |
| Type | eSure high‑efficiency telecom rectifier module |
| AC Input | 85–305VAC, 45–65Hz; Max 22A |
| DC Output | Nominal –48VDC; Adjustable –42V ~ –58VDC |
| Rated Output Power | 3500W |
| Max Output Current | 73A |
| Peak Efficiency | 96.3% |
| Power Factor | >0.99 (50%–100% load) |
| Current Sharing Accuracy | ≤±3% |
| Control Interface | CAN bus |
| Indicators | Green=Normal; Yellow=Alarm; Red=Fault |
| Protection Functions | OVP, OCP, SCP, OTP, Input Undervoltage |
| Dimensions (H×W×D) | 41 × 84.5 × 330 mm |
| Weight | Approx. 1.7 kg |
| Operating Temp | –40°C ~ +75°C |
| Certifications | CE, UL, ETSI, RoHS |
| Warranty | 12 Months |
| Application | Telecom, Base Station, OLT, Data Center |
Applications
4G / 5G mobile base stations and wireless access sites
Telecom OLT and fiber optical access network equipment
Edge data centers and IDC equipment rooms
Microwave transmission and fixed communication systems
Industrial control, automation and critical DC power loads
Compact embedded power systems and communication cabinets
Outdoor communication cabinets and harsh environment scenarios
