Highlight: Customization Backup Battery Cabinet, Outdoor Telecommunication Cabinets Antirust, Customization Outdoor Telecommunication Cabinets
Customization Backup Battery Cabinet Outdoor Telecommunication Cabinets Antirust
Product Description
Battery Cabinet Customization IP55 IP65 IP66 IP67 Rack Cabinets Backup Energy Storage Telecommunication Cabinet Outdoor
Features
Origin | Guangdong, China |
Brand name | Eltek |
Model | EK-ETP002 |
External Size | Customization |
Working | -40°C ~ +55°C |
Warranty | 12 Months |
| Material | Galvanized Steel; Customer Requirement |
Application | Outdoor Telecom Power Electronic Equipment |
Cabinet style | Ground-Stand, Customiation |
Surface treatment | Powder Coating |
Composition | Air conditioner |
Structure | Welded/Frame/Assembly |
| Cabinet Outer Dimension | Customized Size; 1800*600*500mm(H*W*D) |
Weight | 100~225KG |
External Dimension(H*W*D) : Standard 2100*900*900mm or any customized size
Width awailable:600mm,650mm,700mm,750mm,800mm,850mm,900mm or any customized size
Depth awailable:600mm,650mm,700mm,750mm,800mm,850mm,900mm,950mm,1000mm or any customized size
2.Internal capacity: 18U,22U ,27U,30U,32U,35U,37U,40U,42U etc (based on customers requirements)
3.Door :With one front door, with special lock for outdoor cabinet (support padlock)
4.Thickness: 19’’rails: 2.0mm, outer panel adopt 2.0mm galvanized sheet, the top, the bottom, the side and
the door panel with the air conditioner wrapped with 30mm PIR thermal insulation material.
5.Cooling method: with air conditioner/Fans
6.Surface treatment: Painting, plasma electrostatic painting, hot galvanized, powder coating, polishing, brushing.
7.Mounting method:Floor mounted
8.Cabinet Accessories:
1* Temperature and humidity sensor,
1* Smoke sensor ,
2* Door limit sensor ,
1*DC 48V 12W LED light,
1* Document holder,
1* UK type 220V outlet,
1* Grounding bar,
2* L-rail, 8* PG21+ 8* PG29,
1* 16 pin terminal block (UK2.5N)
9.IP55, color:RAL7035/Pantone428C
Extensive product range: We offer products from top brands like HUAWEI, EMERSON, ELTEK, DELTA, FLATPACK, and more.
Quality assurance: Rigorous testing and aging tests ensure high-quality products that meet industry standards.
Excellent after-sales service: Our dedicated customer support team is always available to assist you.
OEM/ODM services: We can customize our products to meet your specific requirements.
Competitive pricing: We offer high-quality products at reasonable prices.
