EPC4860/1800-FA31 Weatherproof Outdoor Telecom Cabinet
IP55 High Protection: Strictly compliant with IP55 protection standard, effectively blocking rainwater, dust and mist, fully adapting to long-term exposed outdoor environments.
Premium Corrosion Resistance: Made of high-strength cold rolled steel, matched with outdoor anti-rust coating and sealing technology, resisting salt spray, corrosion and aging in coastal and humid areas.
Excellent Electrical Performance: Rated 220V AC input (45~65Hz), power factor ≥0.99, system efficiency ≥93.5, low power loss and energy-saving operation.
Adjustable DC Output: Standard -48V DC output, adjustable voltage range -43.2V ~ -57.6V, compatible with various telecom devices and storage batteries.
Lightweight & Compact: Overall weight ≤33kg (including rectifiers and package), compact size saves on-site installation space.
Multiple Installation Options: Supports rack mount, wall mount and floor installation, flexible to adapt to different site conditions.
Full Safety Protection: Built-in overvoltage, overcurrent, short-circuit and overtemperature protection, plus lightning protection to ensure safe operation of power equipment.
Wide Temperature Adaptation: Normal operation at -40℃ ~ +55℃, coping with extreme cold and high temperature outdoor climates.
Integrated Design: Combines rectifier, power distribution and battery compartment, simplifying system deployment and reducing engineering costs.
Easy Maintenance: Front access design with standard door lock, convenient for daily inspection and module replacement.
4G/5G outdoor communication base stations and pole-mounted cell sites
FTTX fiber-optic broadband outdoor access nodes
Microwave communication and signal transmission equipment
Remote unattended network rooms and roadside communication facilities
Outdoor monitoring equipment and industrial backup power systems
| Category | Item | Parameter |
|---|---|---|
| Basic Info | Product Type | IP55 Weatherproof Outdoor Telecom Power Cabinet |
| Model | EPC4860/1800-FA31 | |
| Brand | XINGDA (Emerson/Vertiv Compatible) | |
| Protection Grade | IP55 | |
| AC Input | Rated Voltage | 220V AC |
| Input Frequency | 45 ~ 65Hz | |
| Input Power Factor | ≥ 0.99 | |
| DC Output | Nominal Voltage | -48V DC |
| Adjustable Voltage Range | -43.2 ~ -57.6V DC | |
| Max Output Current | 60A | |
| System Efficiency | ≥ 93.5% | |
| Physical Parameter | External Dimension (Without Base) | 610 × 250 × 700 mm |
| Total Weight | ≤ 33kg (With 2 Rectifiers & Package) | |
| Main Material | Cold Rolled Steel (Anti-corrosion Coating) | |
| Installation | Mounting Type | Rack Mount / Wall Mount / Floor Standing |
| Environment | Operating Temperature | -40℃ ~ +55℃ |
| Storage Temperature | -40℃ ~ +70℃ | |
| Relative Humidity | 5% ~ 100% (Non-condensing) | |
| Service | Warranty Period | 12 Months |
| Customization | Logo, color, structure customizable |
Reliable Outdoor Performance: IP55 waterproof and dustproof + anti-corrosion steel body, suitable for all kinds of harsh outdoor environments.
High Energy Efficiency: High power factor and conversion efficiency reduce long-term power consumption.
Light & Flexible: Lightweight design and diverse installation methods adapt to various site layouts.
Integrated Solution: All-in-one cabinet integrates power and storage, simplifying procurement and construction.
Wide Compatibility: Adjustable DC voltage matches multiple batteries and telecom equipment.
Complete Protection: Multi-layer safety design prevents equipment failure caused by abnormal power and surge.
Customizable Service: Supports personalized modification to meet different project requirements.
Founded in 2008, Shenzhen Pengcheng Electric Technology Co., Ltd. focuses on R&D and sales of telecommunication and data center supporting products. Headquartered in Bao'an, Shenzhen, we have partners across the country.
We supply network energy equipment including telecom power systems, precision distribution cabinets and integrated cabinets (customization available) from ELTEK, Huawei, Vertiv (formerly Emerson), ZTE and CE+T. Our product range also covers UPS, precision air conditioners, batteries and other data room accessories from well-known brands.
All products are strictly tested before delivery. We offer reliable after-sales service and instant spare parts support within warranty to cut your time and costs. Custom OEM/ODM services are also available.
Q: What is the protection level of this cabinet?
A: It adopts IP55 protection grade, with excellent waterproof and dustproof performance for long-term outdoor use.
Q: What are the input and output parameters?
A: Rated AC input is 220V (45~65Hz); DC output is -48V with max 60A, and the voltage is adjustable between -43.2V and -57.6V.
Q: What is the total weight?
A: The total weight including two rectifiers and package is no more than 33kg.
Q: What material is the cabinet made of?
A: It is made of high-quality cold rolled steel with professional anti-corrosion coating.
Q: What is the working temperature range?
A: The operating temperature is -40℃ ~ +55℃, adapting to extreme cold and hot outdoor conditions.
Q: Can I customize logo and color?
A: Yes, we support logo, color and internal structure customization.
Q: What packaging is used for transportation?
A: Adopts solid wooden case packaging to avoid damage during transit.
