Highlight: Eltek FP2 48/2000 HE, eltek 241115.105 48/2000 HE, eltek 241115.105 48Vdc 2000W
| BrandA: | Eltek | Part No.: | 241115.105 |
| Model Name: | FP2 48/2000HE | Effciency: | 96.5% |
| Application: | Telecom Power Core Systems | Input Voltage: | 220Vac |
| Output Voltage: | 48Vdc | Nominal: | 53.5Vdc |
| Frequency: | 50/60HZ | Weight: | 2 Kg |
Product Description
Eltek FP2 48/2000HE 48Vdc 2000W AC / DC module high effciency Part No. 241115.105
Flatpack2 48/2000 HE Rectifier Module The most efficient rectifier in the industry!
The combination of innovative design, efficiency and reliability makes the Flatpack2 HE stand out. With an efficiency up to 96.5%, the losses have been reduced by 50% compared to the current industry standard. In a global perspective, considering the high energy consumption in the telecom industry, this technology breakthrough is not only reducing operational cost for the operators, but it can also have a significant impact.
Applications
Wireless, fiber and fixed line communication
Broadband and network access
Small and large (Flatpack2 HE rectifiers are used in system solutions from 2kW to192kW.)
Parameters
| Product Name | Flatpack2 48/2000 HE |
| Part No. | 241115.105 |
| AC input | |
| Voltage | 85-300vAC (nominal 185-275Vac) |
| Frequency | 45 /66hz |
| Maximum Current | 11.6a max atnomial input and full load |
| Power Factor | ＞0.99 at 50% load or more |
| Input Proection | Varistors for transletn ; Mains fuse in both lines ; Disconnect |
| DC output | |
| Voltage | 53.5Vdc (Range:43.5-57.6Vdc) |
| Output power | 2000W at nominal input |
| Maximum current | 41.7A at 48Vdc |
| Current Sharing | ±5% of max current from 10% to 100% |
| Output Protection | Overvoltage shundown ; Hot plug in ;Short circult ; High temperature protection |
Product Display
