Product Overview
The Huawei R4830G1 is compact high-efficiency digital hot-swap rectifier, specially designed to match Huawei ETP series embedded telecom power cabinets including ETP4890-A2 and related models. Rated 1600W/30A@53.5VDC (up to 1740W under full nominal AC input), it converts wide-range 85~300VAC single-phase mains into adjustable 42~58VDC standard telecom voltage. Adopts advanced full digital control and active PFC topology, peak conversion efficiency reaches 96%, full-load PF≥0.99 and ultra-low THD≤3.5%. Standard 1U slim drawer hot-plug design allows online replacement without cabinet power-off; built-in CAN bus communication links with cabinet monitoring unit for remote parameter adjustment and fault alert, widely applied in indoor FTTx OLT, DSLAM and small-capacity 4G/5G micro base station power configuration and old equipment spare replacement projects.
Key Features
Ultra-wide AC input:85~300VAC(45~66Hz, nominal220VAC), stable operation for unstable municipal grid and diesel generator power supply
Adjustable DC output:42~58VDC(default53.5VDC), max30A continuous current, 1600W rated power(1740W@≥176VAC input, automatic derating below 176VAC)
Active PFC design, full-load PF≥0.99, THD≤3.5%, peak efficiency up to 96% to reduce long-term site power consumption
Full hot-swap plug-and-play construction, slim 1U size for high power density cabinet layout
Intelligent thermostatic variable speed fan, auto adjust fan speed by internal temperature to cut idle noise and extend service life
Comprehensive multi-protection:OVP/UVP/OCP/SCP/OTP plus AC input lightning surge protection
CAN bus communication interface for real-time data upload, remote voltage/current setting via ETP system monitor
Pass CE,UL,TUV,RoHS certification, stable -40℃~+75℃ full-power operation(max4000m altitude)
Technical Specifications
| Item | Details |
| Model | R4830G1 |
| Brand | Huawei |
| AC Input | 85~300VAC,45~66Hz,Nominal220VAC,Max13A |
| DC Output | Adjustable42~58VDC(Nom53.5V),Nom30A/1600W(Max1740W) |
| Peak Efficiency | ≥96% |
| Full Load PF | ≥0.99 |
| THD | ≤3.5% |
| Dimension | 40.8×95.5×208mm |
| Net Weight | ≤1.6kg |
| Cooling | Intelligent Variable Speed Forced Air Cooling |
| Communication | CAN Bus |
| Working Temp | -40℃ ~ +75℃ |
| Max Full-power Altitude | ≤4000m |
| Certifications | CE,UL,TUV,RoHS |
| MOQ | 1 PCS |
| Unit Price | $138/PCS(1~9pcs) |
| Monthly Supply | ≥1000PCS |
| Packing | Export Standard Carton |
| Warranty | 12 Months |
Applications
Huawei ETP4890-A2 Series Cabinet Matching FTTx OLT Embedded DC Power
Indoor Mini 4G/5G Small Cell Base Station Backup Power Module
DSLAM Fiber Access Cabinet Rectifier Spare Replacement
Compact Unmanned Indoor Communication Cabinet Power Supply
Small Edge Server Room Auxiliary DC Power Source
Old ETP Cabinet Low-power Capacity Expansion Project
