Product Overview
The Eltek Flatpack2 60/3000 SHE is a high‑power, ultra‑high efficiency DC rectifier module designed for mission‑critical communication and data center power systems. It converts wide‑range AC input into stable adjustable 60V DC output, providing reliable power supply and battery charging for 4G/5G base stations, microwave transmission, OLT equipment, edge data centers and industrial control scenarios.
Adopting patented topology and advanced digital control technology, this module delivers up to 3000W output power with peak efficiency up to 97.8%, featuring compact size, hot‑swap capability, complete protection functions and extreme environmental adaptability. As a core component of the Flatpack2 power system, it ensures stable, energy‑saving and maintenance‑free operation for critical DC power applications.
Key Features
Ultra‑high peak efficiency up to 97.8%, significantly reducing energy consumption and heat dissipation
Wide AC input range 85–300VAC, 45–66Hz, compatible with global power grids and unstable utility power
Adjustable DC output 54–72VDC, max output current 50A, rated power 3000W to meet high‑power load demands
Hot‑swappable design, supports online plug‑and‑play replacement without system power off
High power density and compact structure, easy for rack integration and system capacity expansion
Full electrical protection: overvoltage, overcurrent, short circuit, overheating, input transient protection
Excellent high‑temperature resistance, stable full‑power output in harsh environments
Compliance with IEC 62368‑1, EN 61000‑6, ETSI, RoHS and global safety & EMC standards
Wide operating temperature range -40°C to +75°C, adapts to outdoor cabinets and extreme environments
Technical Specifications
| Item | Details |
|---|
| Brand | Eltek |
| Model | Flatpack2 60/3000 SHE |
| Part Number | 241119.706 |
| Type | Rectifier Module |
| AC Input | 85–300VAC, 45–66Hz; Max 16A RMS |
| Power Factor | >0.99 (50%–100% load) |
| DC Output | 54–72VDC adjustable; Nominal 60VDC |
| Rated Power | 3000W |
| Max Output Current | 50A @ 60VDC |
| Peak Efficiency | 97.8% |
| Current Sharing | ±5.0% of max current |
| Static Voltage Regulation | ±0.5% (10–100% load) |
| Operating Temperature | -40°C ~ +75°C |
| Dimensions (W×H×D) | 109 × 44 × 327 mm |
| Net Weight | Approx. 2.05 kg |
| Protection Functions | OVP, OCP, SCP, OTP, Input Transient Protection |
| Certifications | IEC 62368‑1, EN 61000‑6, ETSI, RoHS |
| Warranty | 12 Months |
| Application | Telecom Base Station, Data Center, Industrial Control, Microwave Transmission |
Applications
4G / 5G mobile base stations and wireless access sites
Telecom OLT and fiber optical access network equipment
Edge data centers and IDC equipment rooms
Microwave transmission and fixed communication systems
Industrial control, automation and critical DC power loads
Outdoor communication cabinets and compact power systems
Special power supply for marine, offshore and harsh environments
